Feature:

• Rotating rain and spray nozzles designed to JIS specifications

• Speed control for the rotating spray nozzles

• Stationary product shelf - A rotating shelf is optional: see options

• Water pressure regulators, gauges and flow meters

• Special high-volume floor drain system to rapidly drain water out of the chamber

• Interior chamber size is the smallest possible area using the JIS specified nozzles

• Standard:

• GB10485-89

• GB4208-93

• GB/T4942

• Corresponding IEC ISO & ASTM standards

• Specification

• Model	BK-60		BK-90	BK-120	BK-200
  Standards	ISO9227, CNS3627,3885,4159,7669,8886, JIS D-0201, H-8502, H-8610, K-5400, Z-2371, ISO 3768, 3769, 3770, ASTM B-117, B-268, GB-T2423, GJB 150.
  Test chamber capacity (L)	108L	270L		600L	1440L
  Temperature	Test chamber			NSS.ACSS 35°C±1°C/CASS 50°C±1°C
  	Air cylinder			NSS.ACSS 47°C±1°C/CASS 63°C±1°C
  Test chamber size LxWxD(cm)	60*45*40	90*60*50		120*100*50		200*120*60
  Max volum of test liquid (L)	15	25		40		40
  Volume LxWxD(cm)	107*60*118	141*88*128		190*130*140		270*150*150
  Power	AC220V,10A	AC220V,15A		AC220V,30A		AC220V,30A
  Spray quantity	1.0~2.0ml/80cm2/h
  PH	6.5~7.2         3.0~3.2
