Technical specifications:

Burner: Made of stainless steel, 200 * 200 * ¥ 3.5 (mm).

Gas flow rate: 0-50L/MIN.

Air flow rate: 0-50L/MIN.

Combustion gas: methane with a purity of 99.5%, or coal gas of equivalent purity. (Provided by the customer)

Measurement of furnace pressure: Using a 0.5 level pressure transmitter.

Timer: 0-99S/min/h.

Strong exhaust system: This machine is equipped with a strong exhaust fan. After the test is completed,

start the exhaust fan system to exhaust the exhaust gas outdoors. (Companies with additional environmental

requirements can design exhaust gas filtration devices to ensure that the air is not contaminated by exhaust gas)

Ignition method: High voltage automatic ignition.

Test bracket: L380 * W380 * H1000 (MM), made of stainless steel.

Air stabilizer: A box located below the burner. Lay wire mesh at the bottom and fiberglass felt on top.
