Product parameters:

1. Maximum test force single column parameter: customer selectable 100N,500N,1KN,2KN,5KN

2. Testing machine level 0.5/1.0

3. Load measurement range: 0.2%~100% FS (0.5 level)/1%~100% FS (1.0 level)

4. Relative error of indication value ± 0.2% (level 0.5) ± 1% (level 1.0)

5 Test force resolution 1/± 500000 FS (full range resolution remains unchanged)

6. Deformation measurement range: 0.2%~100%

7 Force control rate adjustment range 0.005%~5% FS/S

9. The deformation rate adjustment range is 0.005-5% FS/s;

11. The displacement rate adjustment range is 0.01-500mm/min;

The displacement rate control accuracy is within ± 0.2% of the set value;
